Airtac 4M Solenoid Valve 4M21006BI
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M21006BI Solenoid Valve Technical Details
- Model: 4M21006BI
- Type: 5/2-way double solenoid (dual-coil latching)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.9 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 l/min (ANR)
- Response time: ≤30ms (actuation), ≤20ms (release)
- Weight: 320g ±5g
- Dimensions: 60mm(L) × 40mm(W) × 85mm(H)
- Seal material: Heat-resistant HNBR (-20℃ to 120℃)
- Temperature range: -5℃ to 80℃ (with silicone grease lubrication)
- Power consumption: 2.8W (DC), 5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (with O-ring seal)
- Cycle rate: ≤5Hz (continuous operation)
High-flow bistable solenoid valve with dual-coil memory function, maintaining position during power loss. Features anti-vibration design with copper alloy core and aluminum alloy body. Includes manual override button for system debugging. Requires 5μm filtered air with oil mist (ISO 8573-1 class 4).
- Robotic arm clamping systems (automotive assembly lines)
- Plastic injection molding machine actuators
- CNC machine tool chuck control
- Bottle capping/packaging machinery
- Elevator braking systems (fail-safe position hold)
Installation guidelines:
Mount in vibration-damped position using M4 mounting screws. Maintain 15mm minimum
clearance around coils for heat dissipation. Perform monthly lubrication through
designated grease ports under continuous operation conditions.
| Property | Property Value |
|---|---|
| sku | 4M21006BI |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
