Airtac 4M Solenoid Valve 4M21008AI
$25.55
Regular price
$33.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
4M21008AI
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Internal pilot-operated design;
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15° maximum deviation from vertical orientation.
Use PTFE tape on male threads only, leaving 1.5 thread turns exposed.
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M210-08-AI Solenoid Valve Specifications
- Model: 4M210-08-AI (4M21008AI)
- Type: 5/2-way double solenoid (double coil)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Flow capacity: 750 l/min (Cv=1.3)
- Voltage options: AC110V 50/60Hz, AC220V 50/60Hz
- Response time: ≤30ms (exhaust to action)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: 4.2VA (AC models)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
- Weight: 350g ±5% (without accessories)
- Dimensions: 55mm(L) × 50mm(W) × 80mm(H)
High-flow 5-port pneumatic valve with dual independent coils for precise bi-directional control. Features brass body with hard anodized aluminum sleeve for corrosion resistance. Requires filtered (≤40μm), lubricated or non-lubricated air. Compatible with ISO 15407-1 standards.
Industrial Applications:
- Multi-position cylinder control in assembly lines
- Clamping/unclamping mechanisms in CNC machinery
- Pneumatic actuator reversal systems
- Textile machinery tension control
- Plastic injection molding ejectors
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15° maximum deviation from vertical orientation.
Use PTFE tape on male threads only, leaving 1.5 thread turns exposed.
| Property | Property Value |
|---|---|
| sku | 4M21008AI |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
