Airtac 4M Solenoid Valve 4M21008B
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M210-08B Solenoid Valve Technical Details
- Model: 4M210-08B (4M21008B)
- Valve type: 5-port/2-position, double solenoid
- Port configuration: 1/4" BSPP (G1/4)
- Operation mode: Double coil latching (pneumatic pilot)
- Max operating pressure: 1.0 MPa
- Min operating pressure: 0.2 MPa
- Voltage variants: DC12V (0.8W), DC24V (1.2W), AC110V (2.5VA), AC220V (3VA)
- Flow capacity (Cv): 1.4
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: HNBR (Hydrogenated Nitrile) for high oil resistance
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Weight: 680g ±5%
- Dimensions: 130mm(L) × 52mm(W) × 50mm(H)
- Port thread depth: 12mm
- Protection class: IP67 (dustproof & waterproof)
- Expected lifespan: 50 million cycles (under standard conditions)
Industrial-grade directional control valve featuring bi-stable latching mechanism for energy-efficient operation. The dual-coil design maintains position without continuous power, with hardened brass body for chemical resistance. Includes manual override and LED status indicator. Requires ISO 8573-1:2010 Class 3 compressed air (max 50mg/m³ oil content).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with position memory
- Battery production vacuum handling
- Textile machinery tension control
Installation protocol:
Mount on vibration-dampening brackets with M5 fasteners (3.5Nm torque).
Maintain 15cm clearance above valve for heat dissipation.
Use AirTAC XF2500 series lubricator for optimal seal performance.
| Property | Property Value |
|---|---|
| sku | 4M21008B |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
