Airtac 4M Solenoid Valve 4M21008B-AM
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M21008B-AM Solenoid Valve Specifications
- Model: 4M21008B-AM
- Type: 5/2-way double solenoid (pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: 320g ±5% (without connectors)
- Dimensions: 78mm(L) × 52mm(W) × 83mm(H)
- Flow coefficient (Cv): 1.8 at 0.5 MPa
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -10℃ to 80℃ (non-freezing environment)
- Power consumption: ≤2.8W (DC) / ≤4.5VA (AC)
- Response time: ≤30ms (energize), ≤50ms (de-energize)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
High-flow bistable solenoid valve with dual coil redundancy, featuring manual override and position-indication LEDs. The aluminum alloy body with hard anodized coating resists chemical corrosion and mechanical wear. Designed for continuous duty cycles up to 1 million operations with ≤5μm filtered air (ISO 8573-1 class 3).
- Automated assembly line clamping systems
- Textile machinery cylinder control
- Plastic injection molding ejectors
- Semiconductor wafer handling robots
- Beverage filling station actuators
Installation note:
Mount in vibration-free environments using M4 mounting screws (not included).
Maintain 15mm clearance below valve for manifold heat dissipation.
Use copper-free anti-seize compound on threads in humid environments.
Maintenance alert:
Replace internal filters every 2,000 operating hours in high-particulate environments.
Never lubricate - pre-lubricated air supply required.
| Property | Property Value |
|---|---|
| sku | 4M21008B-AM |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
| Standard Voltage | DC24V |
