Airtac 4M Solenoid Valve 4M220-06-A
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M220-06-A Solenoid Valve Specifications
- Model: 4M220-06-A
- Type: 5/2-way double solenoid (pilot-operated)
- Port size: PT3/8 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V
- Weight: 220g ±5g
- Dimensions: 54mm(L) × 40mm(W) × 72mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -10℃ to 80℃ (with intermittent 90℃ tolerance)
- Power consumption: ≤2.5W (DC) / ≤3.5VA (AC)
- Response time: ≤20ms (at 0.5MPa)
- Flow coefficient (Cv): 1.2
- Protection rating: IP67 (dustproof & waterproof)
- Port thread depth: 12mm (PT3/8)
High-flow solenoid valve with dual-coil latching design for stable position retention without continuous power. Features anodized aluminum body with copper-free stainless steel core for corrosion resistance in humid environments. Optimized pilot structure ensures reliable operation under vibration conditions (up to 10Hz/2mm amplitude). Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 air quality.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers and spindle brakes
- Textile machinery tension control
- Food processing pneumatic circuits (oil-mist-free operation)
Installation guidelines:
Mount in any orientation but avoid downward-facing exhaust ports.
Maintain ≥15mm clearance around solenoid coils for heat dissipation.
Use locking-type connectors (e.g., M12-4pin) for vibration-prone environments.
| Property | Property Value |
|---|---|
| sku | 4M220-06-A |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
