Airtac 4M Solenoid Valve 4M220-08-A
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M220-08-A Solenoid Valve Technical Details
- Model: 4M220-08-A
- Type: 5/2-way double pilot operated (monostable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V
- Weight: ~650g
- Dimensions: 85mm(L) × 56mm(W) × 90mm(H)
- Flow capacity (Cv value): 2.2
- Seal material: NBR/FKM (optional)
- Temperature range: -5℃ to 80℃ (NBR), -5℃ to 150℃ (FKM)
- Power consumption: ≤2.5W (DC), ≤4.5VA (AC)
- Response time: ≤30ms (exhaust to actuation)
- Interface material: Aluminum alloy (anodized)
- Protection rating: IP67 (dust/water resistant)
- Certification: CE, RoHS compliant
High-flow directional control valve with manual override, featuring double pilot operation for reliable switching in high-vibration environments. The optimized spool design achieves 50% faster response than standard models. Rated for 10 million cycles with ≤0.1% leakage rate. Compatible with ISO 15407-1 mounting interfaces.
- Plastic injection molding machine clamp control
- CNC tool changers with rapid cylinder cycling
- Foundry equipment requiring heat-resistant seals
- Automated assembly line positioning systems
- Wastewater treatment pneumatic actuators
Installation guidelines:
Requires minimum 15mm clearance below valve for exhaust port maintenance.
Use M5 mounting screws with 0.4-0.6Nm torque. Lubricate with ISO VG32 oil
if operating below -5℃. Avoid mounting in orientations where condensed
moisture could pool in pilot channels.
Critical notes:
Not compatible with phosphate ester fluids. Always install downstream
air filter (5μm minimum). Maximum allowable pressure spike: 1.5MPa
(duration <100ms). For continuous operation above 60℃, derate current
by 20%.
| Property | Property Value |
|---|---|
| sku | 4M220-08-A |
| Position | 5 Ports 2 Position |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
