Airtac 4M Solenoid Valve 4M310-10-A
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M310-10-A Solenoid Valve Specifications
- Model: 4M310-10-A
- Type: 3/2-way normally closed (pilot-operated)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Flow capacity: 800 L/min (Cv=1.8)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 1.2 kg (2.65 lbs)
- Dimensions: 150mm(L) × 80mm(W) × 120mm(H)
- Seal material: NBR (Nitrile), optional FKM/Viton
- Temperature range: -20℃ to 80℃ (non-freezing)
- Power consumption: ≤2.5W (DC), ≤4.5VA (AC)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Port thread depth: 13mm (minimum engagement)
High-flow industrial solenoid valve with reinforced brass body for demanding pneumatic systems. Features a wear-resistant piston structure and anti-vibration coil design, optimized for continuous operation in high-cycle applications. Requires 50μm filtered/dried air (ISO 8573-1:2010 Class 4.4.2) with lubrication optional.
- Automotive assembly line clamping systems
- Injection molding machine ejectors
- Palletizer cylinder control
- Food packaging air knife systems
- Wastewater treatment plant actuators
Installation note:
Mount horizontally to prevent debris accumulation. Use flexible tubing
connections to absorb vibration. Allow 20mm clearance for heat dissipation.
Lubricate every 5 million cycles under continuous duty.
| Property | Property Value |
|---|---|
| sku | 4M310-10-A |
| Position | 5 Ports 2 Position |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
