Airtac 4M Solenoid Valve 4M320-10-A
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M320-10-A Solenoid Valve Specifications
- Model: 4M320-10-A
- Type: 5/2-way monostable (pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V
- Weight: 480g ±5%
- Dimensions: 72mm(L) × 54mm(W) × 78mm(H)
- Flow coefficient (Cv): 2.1
- Seal material: Heat-resistant NBR (-5℃ to 120℃)
- Valve body material: Die-cast aluminum with anodized finish
- Response time: ≤15ms (exhaust to actuation)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (both inlet and outlet)
High-flow solenoid valve engineered for industrial automation systems requiring rapid cycling. Features dual-pressure operation capability and enhanced heat dissipation ribs. The pilot-operated design ensures reliable switching under vibration-prone conditions. Compatible with ISO 15407-1 standards for pneumatic components.
- Plastic injection molding machine clamp control
- Automated production line cylinder sequencing
- Textile machinery air circuit switching
- CNC machine tool fixture actuation
- Semiconductor handling equipment
Installation guidelines:
Maintain horizontal mounting position for optimal diaphragm performance.
Use 2x port clearance (minimum 15mm) for service access.
Lubricate with ISO VG32 pneumatic oil if operating below -5℃.
Requires 5μm filtration with auto-drainage.
Do NOT use with oxygen or combustible gases.
Maximum allowable leakage: 50cm³/min at 0.5MPa.
| Property | Property Value |
|---|---|
| sku | 4M320-10-A |
| Position | 5 Ports 2 Position |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
