Airtac 4V100 Solenoid Valve 4V11006AI
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V100 Series Solenoid Valve 4V11006AI Technical Specifications
- Model: 4V11006AI
- Type: 5/2-way single solenoid control (spring return)
- Port configuration: 5 ports (P, A, B, EA, EB) / 2 positions
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.2–1.0 MPa
- Maximum pressure: 1.5 MPa
- Voltage specification: AC220V 50/60Hz (standard), DC24V optional
- Coil insulation class: Class F (155℃)
- Weight: 320g ±5% (including coil)
- Dimensions: 58mm(L) × 34mm(W) × 82mm(H)
- Body material: Die-cast aluminum alloy (surface anodized)
- Seal material: Heat-resistant NBR (Nitrile) - VITON available on request
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Flow coefficient (Cv): 1.8
- Response time: ≤25ms (energize), ≤15ms (de-energize)
- Power consumption: 3.5VA (AC), 4.5W (DC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Manual override: Built-in emergency push button
High-flow directional control valve with rugged construction for industrial automation. Features low-hysteresis spool design for precise cylinder control and integrated surge suppression for extended coil life. Compatible with ISO 5599-1 mounting interface, allowing modular assembly with other pneumatic components.
- Automated assembly line actuators
- Plastic injection molding machine clamps
- CNC machine tool clamping systems
- Material handling equipment (conveyor diverters)
- Textile machinery air circuit control
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (torque ≤1.2N·m).
Maintain 20mm clearance above valve for heat dissipation. Use 5μm air filter
with automatic drain. Lubricated air (ISO VG32) recommended for optimal seal life.
Critical note:
Do not apply pressure during installation/removal. Cycle valve 2-3 times
after long-term storage to redistribute lubricant before system operation.
| Property | Property Value |
|---|---|
| sku | 4V11006AI |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
