Airtac 4V100 Solenoid Valve 4V120-06-A
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V120-06-A Solenoid Valve Specifications
- Model: 4V120-06-A
- Type: 5/2-way double pilot operated (universal function)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 210g ±5% (without connector)
- Dimensions: 65mm(L) × 45mm(W) × 90mm(H)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE buffer
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: ≤2.5W (DC) / ≤5VA (AC)
- Flow coefficient (Cv): 1.8 at 6 bar
- Response time: ≤30ms (at rated voltage)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow solenoid valve with dual-coil latching capability, engineered for heavy-duty pneumatic systems. Features anti-vibration design with copper alloy solenoid housing and multi-stage filtration compatibility. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line clamping mechanisms
- Plastic injection molding machine actuators
- CNC tool changers with position memory
- Foundry equipment requiring heat resistance
- Bidirectional cylinder control in material handling
Maintenance protocol:
Perform quarterly manual override tests to prevent spool sticking.
Use AirTAC VG-008 lubricant for maintenance cycles. Allow 2-minute
cooling intervals during continuous 24V DC operation.
| Property | Property Value |
|---|---|
| sku | 4V120-06-A |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
