Airtac 4V100 Solenoid Valve 4V130C-06-A
The AirTAC Airtac 4V100 Solenoid Valve 4V130C-06-A is a genuine 5/3-way 5/3 double solenoid — closed center solenoid valve with A ports and an effective area of 8.6 mm² (Cv 0.51). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/3-way
- Function5/3 double solenoid — Closed center
- Port sizeA
- Effective area8.6 mm²
- Flow (Cv)0.51
- Series4V100
About the Airtac 4V100 Solenoid Valve 4V130C-06-A
The AirTAC 4V130C-06A is a 5/3-way double-solenoid valve that directs compressed air to double-acting cylinders and actuators, adding a defined center position for controlled stopping. When both solenoids are de-energized, the closed center blocks all ports, holding the cylinder in place at mid-stroke to prevent drift in small clamping or positioning tasks.
Built on the compact 4V100 aluminum body, this AC220V terminal-box model weighs 200 g and delivers an effective area of 8.6 mm2 (Cv 0.51). It suits ~O16-32 mm cylinders and responds in 0.05 s or less, with a 3.5 VA coil that runs directly on common mains voltage.
Airtac 4V100 Solenoid Valve 4V130C-06-A Technical Specifications
| Model | Airtac 4V100 Solenoid Valve 4V130C-06-A |
|---|---|
| Series | 4V100 solenoid valve (spool type) |
| Valve type | 5/3-way |
| Function | 5/3 double solenoid — Closed center |
| Port size | A |
| Exhaust port | A |
| Effective area (Cv) | 8.6 mm² (Cv 0.51) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 200 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 8.6 mm² |
|---|---|
| Flow coefficient | Cv 0.51 |
| Response time | ≤ 0.05 s |
| Coil power | AC 3.5 VA · DC24V 2.8 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: Airtac 4V100 Solenoid Valve 4V130C-06-A
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 1 | Body size (4V100) — sets port & flow. |
| 3 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -A | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V110 (single), 4V120 (double), 4V130C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the Airtac 4V100 Solenoid Valve 4V130C-06-A Is Used
Mid-Stroke Clamping
A small pneumatic clamp on a benchtop fixture stops and holds at an intermediate position, preventing part drift during a two-step assembly process.
Laboratory Positioning
A double-acting actuator on a sampling arm halts precisely mid-travel for a dwell step, then continues its cycle under sequence control.
Compact Indexing Tables
A small rotary actuator pauses at a center position for inspection, using the valve's closed center to maintain orientation before indexing forward.
Is the Airtac 4V100 Solenoid Valve 4V130C-06-A the Right Valve?
Choose the 4V130C-06A when your application needs a 5/3 closed-center function on a 1/8-inch PT port with AC220V power. The closed center is ideal for holding a cylinder at an intermediate position when both solenoids are off, though for suspended loads you must add a pilot-operated check valve or mechanical brake. If your cylinder is larger than ~O32 mm or you need a higher flow coefficient, step up to the 4V200 series (Cv 1.0) for faster actuation.
When replacing an existing valve, match five points: body size (4V100), function (5/3 closed-center, code 30C), port and thread (1/8-inch PT), coil voltage (AC220V), and electrical entry (terminal box). This model can also be mounted on a manifold base to build a compact multi-valve station.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
Airtac 4V100 Solenoid Valve 4V130C-06-A FAQ
With an effective area of 8.6 mm2 (Cv 0.51) and a max frequency of 3 cycles per second, this valve is well-matched to double-acting cylinders in the ~O16-32 mm range. For larger bores or faster cycling, consider the 4V200 series with its higher Cv of 1.0.
When both solenoids are de-energized, the spool moves to the center position and blocks pressure, exhaust, and both cylinder ports. This holds the actuator in place, resisting movement from balanced loads. The AC220V coil draws 3.5 VA and connects via the standard terminal box.
