Airtac 4V100 Solenoid Valve 4V130P-06-A
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V130P-06-A Solenoid Valve Technical Details
- Model: 4V130P-06-A (4V100 Series)
- Valve type: 5/2-way single solenoid, spring return
- Port configuration: PT1/4 (G1/8 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V/24V, AC110V/220V (50/60Hz)
- Max flow rate: 750 L/min (ANR)
- Response time: ≤15ms (at 0.5MPa)
- Seal material: Heat-resistant NBR (nitrile butadiene rubber)
- Ambient temperature: -5℃ to 80℃ (no freezing)
- Viscosity range: ≤1×10⁻³ Pa·s (ISO VG32 equivalent)
- Protection class: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A connector
- Weight: 320g ±5% (with bracket)
- Dimensions: 58mm(L) × 42mm(W) × 75mm(H)
High-flow proportional control valve engineered for industrial automation systems requiring precise directional control. Features brass body with hard-anodized aluminum core for corrosion resistance in humid environments. Optimized flow path design reduces pressure drop by 18% compared to previous generation models.
- Pneumatic punching press clutch/brake systems
- Injection molding machine ejector controls
- Automated food packaging line actuators
- Semiconductor wafer handling robotics
- Train door control systems
Installation guidelines:
Mount horizontally with arrow aligned to airflow direction. Use shock-absorbing
brackets in high-vibration environments. Requires 5μm filtered air with
automatic drain lubricator (ISO VG32 oil recommended).
| Property | Property Value |
|---|---|
| sku | 4V130P-06-A |
| Position | 5-port 3-position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
