Airtac 4V300 Solenoid Valve 4V330P-08-A
2. Spool-type structure ensures excellent sealing performance and responsive actuation;
3. Three-position valves offer three center position configurations (exhaust-closed/exhaust-open/pressure-center);
4. Dual-solenoid two-position valves feature memory function for sustained state retention;
5. Specially honed inner bore minimizes friction resistance, enables low operating pressure, and extends service life;
6. Maintenance-free lubrication system eliminates external lubrication requirements;
7. Manifold-compatible design allows modular assembly, optimizing space utilization;
8. Integrated manual override facilitates installation and commissioning adjustments;
9. Multiple standard voltage options available for flexible integration.
Category: Solenoid Valves | Brand: AirTAC | Series: 4V300
AirTAC 4V330P-08-A Solenoid Valve Technical Specifications
- Model: 4V330P-08-A
- Type: 5/3-way closed center (pilot-operated)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 1200 L/min (ANR)
- Response time: ≤30ms (at rated voltage)
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Body material: Die-cast aluminum with nickel plating
- Protection rating: IP67 (dust/water resistant)
- Weight: 1.2 kg ±5% (including coil)
- Dimensions: 98mm(L) × 52mm(W) × 115mm(H)
- Mounting: ISO 4400 standard pattern
- Manual override: Built-in push-button (optional lockable)
High-flow proportional control valve with center exhaust function, featuring anti-vibration coil design and pressure-balanced spool structure. The optimized flow path reduces pressure drop by 15% compared to previous generation models. Requires 5μm filtered lubricated air (ISO 8573-1 class 4) with oil mist concentration 1:200,000.
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC rotary table positioning control
- Textile machinery pneumatic actuators
- Food processing packaging equipment
Maintenance protocol:
Perform full-stroke cycling monthly if idle. Use AirTAC VG68 pneumatic oil
for lubrication. Avoid mounting near high-frequency vibration sources (>50Hz).
| Property | Property Value |
|---|---|
| sku | 4V330P-08-A |
| Position | 5-port 3-position |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
