Airtac 4V300 Solenoid Valve 4V330P-10-A
2. Spool-type structure ensures excellent sealing performance and responsive actuation;
3. Three-position valves offer three center position configurations (exhaust-closed/exhaust-open/pressure-center);
4. Dual-solenoid two-position valves feature memory function for sustained state retention;
5. Specially honed inner bore minimizes friction resistance, enables low operating pressure, and extends service life;
6. Maintenance-free lubrication system eliminates external lubrication requirements;
7. Manifold-compatible design allows modular assembly, optimizing space utilization;
8. Integrated manual override facilitates installation and commissioning adjustments;
9. Multiple standard voltage options available for flexible integration.
Category: Solenoid Valves | Brand: AirTAC | Series: 4V300
AirTAC 4V330P-10-A 5/2-Way Solenoid Valve Specifications
- Model: 4V330P-10-A (4V300 series)
- Function: 5/2-way pilot-operated with spring return
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Effective flow rate: 850 l/min (Cv=1.2)
- Response time: ≤20ms (at 0.5MPa)
- Weight: 340g ±5% (without connector)
- Dimensions: 56mm(L) × 45mm(W) × 72mm(H)
- Seal materials: NBR/FKM (optional high-temp seals)
- Ambient temperature: -5℃ to 60℃ (standard seals), -20℃ to 80℃ (FKM option)
- Coil insulation class: Class F (155℃)
- Protection rating: IP67 (connector installed)
- Port thread depth: 12mm (full-threaded entry)
High-flow solenoid valve with reinforced pilot mechanism for industrial automation systems. Features dual-pressure operation capability and surge-protected coil design. Requires 5μm filtered lubricated air (ISO 8573-1 class 4) with 20-50 cSt oil viscosity. Compatible with ISO 5599-1 mounting interface.
- Pneumatic cylinder sequencing in assembly lines
- Plastic injection molding machine actuators
- Textile machinery double-acting cylinder control
- Automated material handling systems
- Packaging machine clamp positioning
Installation protocol:
Mount with 1.5-2Nm torque using M5 mounting screws. Maintain minimum
15mm clearance below valve for exhaust port ventilation. Lubricate
O-rings with silicone grease (JIS K2220 2-grade) during maintenance.
| Property | Property Value |
|---|---|
| sku | 4V330P-10-A |
| Position | 5-port 3-position |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
