Airtac 4V400 Solenoid Valve 4V42015A-AM
2. Spool-type structure with excellent sealing performance and rapid response characteristics;
3. Three-position solenoid valve offers three center configuration options: closed center, exhausted center, and pressure center;
4. Dual-coil two-position configuration features latching (memory) function;
5. Precision-machined bore with low friction design ensures minimal actuation pressure and extended service life;
6. Maintenance-free operation without lubrication requirements;
7. Manifold-mountable design for space-efficient system integration;
8. Integrated manual override for simplified commissioning and troubleshooting;
9. Multiple standard voltage configurations available.
Category: Solenoid Valves | Brand: AirTAC | Series: 4V400
AirTAC 4V400 Series Solenoid Valve 4V42015A-AM Technical Details
- Model: 4V42015A-AM
- Type: 5/2-way double solenoid (dual coil)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Weight: 320g ±5% (with connectors)
- Dimensions: 80mm(L) × 45mm(W) × 55mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (operating fluid)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤20ms (exhaust to actuation)
- Flow coefficient (Cv): 1.2
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
High-flow directional control valve with dual manual override and LED status indicators. Features brass alloy body with hard anodized aluminum solenoid assembly for corrosion resistance in humid environments. Designed for precision bi-directional cylinder control with 3-position memory function when de-energized.
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with positional feedback
- Food processing pneumatic actuators (oil-free version available)
- Elevator brake control systems
Installation guidelines:
Mount with vibration-damping gaskets in high-shock environments.
Maintain minimum 20mm clearance below valve for condensate drainage.
Use M3x8 stainless steel screws (torque ≤0.4Nm) for panel mounting.
| Property | Property Value |
|---|---|
| sku | 4V42015A-AM |
| Position | 5 Ports 2 Position |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
