Airtac 5A Pneumatic Control Valve 5A21006
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A21006 Pneumatic Control Valve Technical Specifications
- Model: 5A21006
- Type: 5-port 2-position (5/2-way) pilot-operated valve
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure range: 0.2–1.0 MPa
- Max flow capacity: 850 L/min (ANR)
- Actuation type: Air pilot control (single/double available)
- Response time: ≤50 ms (at 0.5 MPa)
- Voltage compatibility: 12-240V DC/AC (solenoid version optional)
- Weight: 480±10g (with accessories)
- Dimensions: 72mm(W) × 50mm(H) × 110mm(L)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature tolerance: -10℃ to 120℃ (with intermittent peak 150℃)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤0.02 MPa
- Protection class: IP67 (splash/oil resistant)
High-flow pneumatic directional control valve featuring low pilot pressure activation (≥0.25MPa) and corrosion-resistant aluminum alloy body. Designed for heavy-duty industrial automation with optional manual override. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.2 purity standards.
- Plastic injection molding machine clamp control
- Automotive assembly line actuators
- Paper processing cylinder drives
- Food packaging vacuum/pressure systems
- Metal stamping press automation
Installation guidelines:
Mount with vibration-damping brackets in horizontal orientation.
Maintain 15mm clearance for heat dissipation. Lubricate using ISO VG32
pneumatic oil if air line isn't pre-lubricated. Test cycle 3-5 times
before full operation.
| Property | Property Value |
|---|---|
| sku | 5A21006 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
