Airtac 6A Pneumatic Control Valve 6A0510M5
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A0510M5 Pneumatic Control Valve Specifications
- Model: 6A0510M5
- Type: 5/2-way (double solenoid or single solenoid with spring return options)
- Port size: PT1/4 (G1/8 optional, M5 manifold base)
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Max flow rate: 750 L/min (ANR) at 0.5 MPa
- Actuation type: Pneumatic pilot control
- Weight: 320g ±5% (including manifold base)
- Dimensions: 55mm(L) × 50mm(W) × 50mm(H) (body only)
- Manifold footprint: 12mm pitch (ISO 5599-1 compliant)
- Seal material: HNBR rubber (high-temp variant available)
- Temperature range: -5℃ to 60℃ (extended to 80℃ with FKM seals)
- Response time: ≤50ms (at 0.5 MPa)
- Leakage: ≤3 bubbles/min (per ISO 6953-3)
- Port thread depth: 10mm (minimum engagement)
High-flow modular valve with multi-position mounting capability, featuring a corrosion-resistant anodized aluminum body. The 6A0510M5's low-power pilot design enables compatibility with small control valves (≥0.15 MPa pilot pressure). Integrated silencer reduces exhaust noise to ≤70 dB(A).
- Multi-axis pneumatic actuator sequencing
- Plastic injection molding machine clamp control
- Automated conveyor diverters
- Tire manufacturing curing presses
- Bottle cap torque-testing equipment
Maintenance protocol:
Lubricate spool every 2 million cycles using ISO VG32 turbine oil.
For vertical installation, position exhaust ports downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | 6A0510M5 |
| Port Size | M5 |
