Airtac 6A Pneumatic Control Valve 6A0520M5
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A0520M5 Pneumatic Control Valve Specifications
- Model: 6A0520M5 (6A Series)
- Valve type: 5/2-way pneumatic pilot operated
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 850 L/min (ANR)
- Actuation method: Air pilot (double)
- Weight: 450g ±5%
- Dimensions: 70mm(L) × 45mm(W) × 95mm(H)
- Seal material: Heat-resistant NBR (+80℃ grade)
- Temperature range: -10℃ to 80℃ (with intermittent peaks at 120℃)
- Response time: ≤50ms (at 0.5MPa)
- Port thread depth: 12mm (minimum engagement)
- Protection rating: IP67 (dust/water resistant)
- Housing material: Reinforced PBT + aluminum alloy
High-flow directional control valve with dual pneumatic pilot operation, featuring rapid switching and optimized flow paths for industrial automation. The hardened aluminum alloy actuator ensures 1,000,000+ cycle durability. Compatible with ISO 15407-1 standards, includes manual override capability for emergency control.
- Pneumatic cylinder sequencing in assembly lines
- High-speed packaging machine actuators
- Plastic injection molding machine controls
- Automotive tire assembly systems
- Food processing pneumatic circuits (oil-resistant version available)
Installation guidelines:
Mount with M5 screws (torque ≤1.2N·m), maintain horizontal tubing alignment.
Use 5μm filtered air with automatic drain. Lubrication not required but
compatible with ISO VG32 pneumatic oil if used. Allow 15mm clearance
below valve for exhaust dispersion.
| Property | Property Value |
|---|---|
| sku | 6A0520M5 |
| Port Size | M5 |
