Airtac 6A Pneumatic Control Valve 6A0530CM5
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A0530CM5 Pneumatic Control Valve Technical Details
- Model: 6A0530CM5 (6A Series)
- Valve type: 5-port 3-position closed center
- Control method: Air pilot operated (double solenoid optional)
- Port size: PT1/4 (G1/4 BSPP thread standard)
- Operating pressure range: 0.2–0.8 MPa (29–116 PSI)
- Max flow capacity: 1,200 NL/min (Cv=1.8)
- Response time: ≤50 ms (at 0.5 MPa)
- Seal material: Heat-resistant NBR (Nitrile) up to 80℃
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Weight: 680g ±2% (excluding accessories)
- Dimensions: 78mm(L) × 54mm(W) × 104mm(H)
- Port configuration: 1(P) 2(A) 3(R) 4(B) 5(S)
- Manual override: Built-in emergency switch (push-lock type)
- Expected lifespan: 10 million cycles (under standard conditions)
High-flow directional control valve optimized for mid-pressure pneumatic systems. Features dual exhaust ports (R/S) for rapid cylinder retraction and a symmetrical flow path design reducing pressure drop by 15% compared to standard models. Requires 5μm filtered air with ISO 8573-1:2010 Class 3 cleanliness. Lubrication-free operation compatible with ISO VG32 hydraulic oil if needed.
- Automated assembly line clamping/unclamping systems
- Plastic injection molding machine ejectors
- Textile machinery tension control units
- Automotive welding robot positioners
- Food processing pneumatic diverters (non-contact areas)
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 20mm clearance below valve for condensate drainage.
Use M5x0.8 mounting screws with 0.4-0.6Nm torque.
Pipe connections should follow ISO 1179-2 standards.
| Property | Property Value |
|---|---|
| sku | 6A0530CM5 |
| Port Size | M5 |
