Airtac 6A Pneumatic Control Valve 6A12006
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A12006 Pneumatic Control Valve Specifications
- Model: 6A12006
- Type: 5/2-way monostable (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa
- Max flow capacity: 850 L/min (ANR)
- Cv value: 1.3
- Response time: ≤50 ms (at 0.5 MPa)
- Actuation type: Air pilot operated
- Seal material: Heat-resistant NBR (up to 120℃ peak)
- Temperature range: -10℃ to 80℃ (continuous operation)
- Weight: 280g ±5%
- Dimensions: 58mm(L) × 34mm(W) × 78mm(H)
- Port thread depth: 10mm (fully engaged)
- Housing material: Reinforced PBT with aluminum alloy sleeve
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
High-flow pneumatic directional valve featuring rapid switching and low pilot consumption (≥0.25MPa control pressure). Optimized spool design reduces "sticky valve" issues in humid environments. Includes manual override button for system debugging. Requires ISO 8573-1:2010 Class 3 compressed air (max 50mg/m³ oil content).
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with rapid cycle demands
- Textile machinery air cylinder sequencing
- Beverage filling station pneumatic circuits
Installation note:
Mount with vibration-damping brackets in high-frequency applications.
Lubricate pilot ports with ISO VG32 turbine oil during maintenance.
Allow 15mm clearance below valve for exhaust condensation drainage.
| Property | Property Value |
|---|---|
| sku | 6A12006 |
| Port Size | PT1/8 |
