Airtac 6A Pneumatic Control Valve 6A120M5
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A120M5 Manual Pneumatic Control Valve Technical Details
- Model: 6A120M5 (6A Series)
- Type: 3-position 5-way manual/pneumatic pilot operated
- Port configuration: 5 ports (P, A, B, R1, R2)
- Thread standard: M5×0.8 tapered threads
- Effective area: 120mm² (critical flow path)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Max flow rate: 850 NL/min (ANR)
- Actuation force: ≤5 N (manual lever operation)
- Weight: 347g ±5g (including accessories)
- Dimensions: 75mm(L) × 42mm(W) × 65mm(H)
- Body material: Aluminum alloy ADC12
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature range: -10℃ to 120℃ (dry air)
- Lubrication: Pre-lubricated (ISO VG32 equivalent)
- Mounting: Direct panel mounting with M4 screws
Industrial-grade manual override valve with positive center position, featuring dual exhaust ports for rapid cylinder cycling. The hardened aluminum body withstands vibration in mobile applications. Includes dust-resistant lever mechanism with tactile position feedback. Requires ISO 8573-1:2010 Class 3 compressed air.
- Production line emergency stop systems
- Material handling equipment manual override
- Plastic injection molding machine clamp control
- Textile machinery pneumatic sequencing
- Battery manufacturing pressurization units
Maintenance advisory:
Perform quarterly lubrication of pivot points using MIL-PRF-6085D grease.
Ensure exhaust ports face downward when installed in dusty environments.
| Property | Property Value |
|---|---|
| sku | 6A120M5 |
| Port Size | M5 |
