Airtac 6A Pneumatic Control Valve 6A130E06
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A130E06 Pneumatic Control Valve Specifications
- Model: 6A130E06
- Type: 5/2-way pilot-operated with spring return
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Max flow capacity: 850 L/min (Cv=1.2)
- Voltage options: DC12V/24V, AC110V/220V (coil optional)
- Response time: ≤20ms (at 0.5MPa)
- Weight: 620g ±5% (with coil)
- Dimensions: 98mm(L) × 50mm(W) × 53mm(H)
- Seal material: NBR (Nitrile) standard, optional FKM/Viton
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
- Manual override: Built-in push-button (optional lockable)
High-flow pneumatic directional control valve featuring low power consumption (≤2.2W) and corrosion-resistant aluminum alloy body. Designed for rapid cycling applications with 50 million cycle durability rating. Requires 5μm filtered/dried air (ISO 8573-1 class 3.4.2) and lubrication-free operation. Features LED status indicator on coil (select models).
- Automated production line actuators
- Plastic injection molding machines
- Textile machinery cylinder control
- Automotive assembly clamping systems
- Food processing pneumatic circuits (FDA-compliant seals available)
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (torque ≤1.2N·m).
Maintain minimum 15mm clearance around exhaust ports. Lubricate sliding parts
with ISO VG32 turbine oil if used in high-cycle applications (>5Hz).
| Property | Property Value |
|---|---|
| sku | 6A130E06 |
| Port Size | PT1/8 |
