Airtac 6A Pneumatic Control Valve 6A130PM5
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A130PM5 Pneumatic Control Valve Technical Details
- Model: 6A130PM5
- Type: 5/2-way pneumatic pilot operated valve
- Control method: Air signal actuation (no solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Flow capacity: 1,100 Nl/min (ANR) at 0.5 MPa
- Response time: ≤50ms (pilot pressure ≥0.3 MPa)
- Weight: 280g ±5% (excluding accessories)
- Dimensions: 56mm(L) × 38mm(W) × 76mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Temperature range: -10℃ to 80℃ (with silicone seals optional for -20℃)
- Port thread depth: 12mm (minimum engagement required)
- Housing material: Reinforced PBT with glass fiber
- Cycle life: ≥5 million operations (under rated conditions)
Robust mechanical valve designed for harsh industrial environments, featuring dual-pressure operation capability and manual override. The direct air-pilot design eliminates electrical components, making it ideal for explosive atmospheres. Optimized flow path reduces pressure drop by 18% compared to previous 5A series models.
- Foundry equipment controls (sand blasting machines, die casting)
- Plastic injection molding machine clamp systems
- Railway braking system pilot valves
- High-cycle production line actuators (stamping presses, riveting)
- Chemical plant pneumatic diverters
Operation note:
Requires minimum 0.25 MPa pilot pressure for reliable switching.
Install downstream filter (≤40μm) when used with lubricant-free air.
Manual override should be operated perpendicular to valve axis.
- Lubrication interval: 6 months (ISO VG32 turbine oil recommended)
- Seal replacement cycle: 2 years under normal operation
- Pressure test requirement: Annual leakage check ≤3 bubbles/min
| Property | Property Value |
|---|---|
| sku | 6A130PM5 |
| Port Size | M5 |
