Airtac 6A Pneumatic Control Valve 6A21006
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A21006 Pneumatic Control Valve Technical Details
- Model: 6A21006 (Series 6A)
- Valve type: 5/2-way pilot-operated (double solenoid)
- Port configuration: PT1/4 (G1/4 optional)
- Operating pressure range: 0.2–0.8 MPa (29–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Effective flow rate: 750 L/min (ANR) at 0.5 MPa
- Seal material: Heat-resistant NBR (Nitrile) with PTFE backup rings
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Response time: ≤20ms (electrical), ≤50ms (full spool stroke)
- Durability: ≥10 million cycles (per ISO 15848 testing)
- Protection class: IP67 (dust/water resistant)
- Weight: 340g ±5g (with solenoids)
- Dimensions: 60mm(L) × 45mm(W) × 50mm(H) (excluding fittings)
- Port thread depth: 10mm (ISO 228-1 standard)
High-flow directional control valve with dual coil redundancy, featuring aluminum alloy body with hard anodized finish for industrial durability. The balanced spool design ensures stable operation under pressure fluctuations. Requires 5μm filtered/dried air (dew point -20℃ below ambient) with ISO 8573-1:2010 Class 3.4.3 air quality.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with rapid cycling requirements
- Foundry equipment requiring heat resistance
- High-cycle packaging machinery (e.g., carton sealers)
Installation protocol:
Mount horizontally with solenoid coils vertical. Use flexible tubing for
vibration isolation in high-cycle applications. Apply thread sealant only
on male ports (not NPT threads). Perform 50+ test cycles before production use.
| Property | Property Value |
|---|---|
| sku | 6A21006 |
| Port Size | PT1/8 |
