Airtac 6A Pneumatic Control Valve 6A230P06
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A230P06 Pneumatic Control Valve Specifications
- Model: 6A230P06 (6A Series)
- Type: 3-position, 5-way pilot-operated pneumatic valve
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Actuation type: Double solenoid or air pilot (varies by configuration)
- Flow capacity: 850 L/min (Cv=1.2)
- Weight: 520g ±5% (without accessories)
- Dimensions: 80mm(L) × 60mm(W) × 42mm(H)
- Seal material: HNBR rubber (standard), FKM available for high-temp
- Temperature range: -10℃ to 80℃ (extended to 120℃ with FKM seals)
- Response time: ≤50ms (at 0.5MPa)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤0.02 MPa
- Protection rating: IP67 (dust/water resistant)
High-flow directional control valve with center closed/exhaust position, featuring anti-vibration brass core and precision-machined spool. Optimized for rapid cycling (up to 5Hz) with built-in manual override. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 cleanliness. Lubricated operation recommended (ISO VG32 turbine oil).
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery tension control systems
- Die-casting machine pneumatic circuits
- Bottle capping station actuator control
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15mm clearance below valve for exhaust port maintenance.
Use Loctite 542 on port threads for permanent installations.
| Property | Property Value |
|---|---|
| sku | 6A230P06 |
| Port Size | PT1/8 |
