Airtac 6A Pneumatic Control Valve 6A230P08
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A230P08 Pneumatic Control Valve Technical Details
- Model: 6A230P08 (6A Series)
- Type: 3-position, 5-way closed center (Double solenoid pilot-operated)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.2–0.8 MPa
- Voltage variants: DC12V, DC24V, AC110V(50/60Hz), AC220V(50/60Hz)
- Weight: 680g ±2% (with connectors)
- Dimensions: 55mm(W) × 44mm(H) × 128mm(L)
- Seal materials: HNBR/Nitrile compound (standard), optional FKM for high temp
- Ambient temperature: -5℃ to 60℃ (extended to 80℃ with FKM seals)
- Flow capacity: CV 2.8 (Kv 2.4) at 0.5MPa
- Response time: ≤50ms (exhaust to full actuation)
- Protection class: IP67 (dustproof and waterproof)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with dual solenoid activation, featuring anti-vibration coil design and corrosion-resistant anodized aluminum body. The center-block design prevents unintended actuator movement during power loss. Requires 5μm filtered lubricated air (ISO 8573-1 class 4) with recommended oil mist concentration of 1:1000.
- Automated production line indexing systems
- Plastic injection molding machine clamp controls
- Automotive wheel hub pressurization units
- Food packaging machine actuator sequencing
- Semiconductor wafer handling robotics
Installation guidelines:
Mount horizontally with arrow direction matching airflow. Maintain minimum
15mm clearance below valve for condensate drainage. Use M5x0.8 mounting screws
with 0.6-0.8Nm torque. Perform manual override test monthly using side pushbuttons.
| Property | Property Value |
|---|---|
| sku | 6A230P08 |
| Port Size | PT1/4 |
