Airtac 6A Pneumatic Control Valve 6A32010
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A32010 Pneumatic Control Valve Technical Details
- Model: 6A32010 (6A series 3-position 5-way)
- Valve type: 5/2-way pneumatic pilot operated
- Port thread: G1/8 (BSPP) with optional NPT1/8 adapters
- Operating pressure range: 0.2–1.0 MPa (29–145 PSI)
- Max flow rate: 850 NL/min (ANR) at 0.5 MPa
- Response time: ≤50 ms (pilot to full stroke)
- Seal material: Heat-resistant HNBR (-10℃ to 120℃)
- Body material: Anodized aluminum alloy (ADC12)
- Weight: 380g ±5% (including manifold base)
- Dimensions: 54mm(W) × 50mm(H) × 117mm(L)
- Porting pattern: ISO 5599-1 standard (compliant with CETOP RP52P)
- Coil protection: Built-in surge suppression & polarity reversal protection
- Manual override: Optional side-mounted emergency actuator
High-flow directional control valve engineered for industrial automation systems requiring precise mid-stroke positioning. Features dual-pressure pilot operation with symmetrical flow paths, achieving 30% faster cycle times than standard 4A series valves. The corrosion-resistant construction withstands humid environments and particle-laden air (up to ISO 8573-1:2010 Class 4.4.3).
- Robotic arm end-effector tooling (gripper rotation/actuation)
- CNC machine tool clamping/unloading mechanisms
- Plastic injection molding machine ejector systems
- Automotive assembly line positioning jigs
- Food processing packaging cylinder sequencing
Installation protocol:
Use M5 mounting screws with 0.6-0.8 N·m torque. Maintain 0.5-1 bar
lower pilot pressure than main pressure. Lubricate with ISO VG32
turbine oil if air line lacks lubrication.
| Property | Property Value |
|---|---|
| sku | 6A32010 |
| Port Size | PT3/8 |
