Airtac 6A Pneumatic Control Valve 6A330C10
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A330C10 Pneumatic Control Valve Specifications
- Model: 6A330C10 (6A Series)
- Type: 5-port 2-position single pneumatic control
- Port configuration: 2 exhaust ports, 2 outlet ports, 1 supply port
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 850 L/min (ANR)
- Actuation pressure: ≥0.3 MPa
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -20℃ to 80℃
- Weight: 380g ±5%
- Dimensions: 58mm(L) × 34mm(W) × 63mm(H)
- Body material: Aluminum alloy (anodized finish)
- Response time: ≤0.1s (at 0.5 MPa)
- Endurance cycles: ≥5 million operations
- Protection rating: IP67 (dust/water resistant)
High-flow directional control valve with rapid switching capability, featuring a reinforced pilot mechanism for stable operation under vibration-prone conditions. The optimized flow path design reduces pressure drop by 18% compared to previous generations. Requires ISO 8573-1 class 3 compressed air (max 40μm particle size, -20℃ pressure dew point).
- Stamping machine clutch/brake systems
- Material handling equipment actuators
- Automotive assembly line tooling
- Plastic injection molding machines
- High-cycle packaging systems (200+ operations/min)
Installation note:
Install upstream filter-regulator-lubricator (FRL) unit within 1m distance.
For horizontal mounting, orient exhaust ports downward to prevent debris accumulation.
Apply thread sealant only on male ports (not NPT fittings). Perform monthly lubrication
checks in high-usage environments.
| Property | Property Value |
|---|---|
| sku | 6A330C10 |
| Port Size | PT3/8 |
