Airtac 6A Pneumatic Control Valve 6A330P10
2. Compatible with base-mounted integrated valve groups for space-saving installations.
Category: Pneumatic Control Valve | Brand: AirTAC | Series: 6A
AirTAC 6A330P10 Pneumatic Control Valve Technical Details
- Model: 6A330P10 (6A Series)
- Type: 3-position, 5-way double solenoid pilot operated
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: 480g ±5% (with connectors)
- Dimensions: 56mm(W) × 45mm(H) × 125mm(L)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Flow capacity: 850 l/min (ANR) at 0.5 MPa
- Response time: ≤50ms (electrical), ≤100ms (mechanical)
- Protection rating: IP67 (dust/water resistant)
- Manual override: Built-in emergency switch
High-flow directional control valve with dual solenoid activation, featuring a center exhaust configuration for mid-position pressure release. The hardened aluminum body with chrome-plated brass core ensures durability in high-cycle applications (≥10 million operations). Includes LED status indicators and surge protection circuitry.
- Automated assembly line actuators
- Plastic injection molding machine controls
- Textile machinery pneumatic systems
- Automotive tire mounting equipment
- Bottle capping/pressurization systems
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use 20-30Nm torque for port fittings. Lubricate with ISO VG32 hydraulic oil
if operating below -5℃. Requires 5μm filtration with auto-drain function.
| Property | Property Value |
|---|---|
| sku | 6A330P10 |
| Port Size | PT3/8 |
