Airtac 6HV Manifold Solenoid Valve 6HV0510M5C200
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV Modular Solenoid Valve 6HV0510M5C200 Technical Details
- Model: 6HV0510M5C200
- Type: 5/2-way monostable (single solenoid)
- Port configuration: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 l/min (Cv=1.3) @ 0.5MPa
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: Heat-resistant NBR (Nitrile) -70% improvement vs standard seals
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Weight: 620g ±2% (including coil)
- Dimensions: 53mm(W) × 125mm(H) × 45mm(D) (manifold interface included)
- Protection class: IP67 (dustproof/water immersion resistant)
- Electrical connection: DIN43650 Form A with LED indicator
- Service life: ≥10 million cycles (tested per ISO 19973-3)
High-flow modular valve with ISO 5599/1 interface for multi-valve manifold stacking. Features zero-pressure differential start capability and surge protection circuitry. Optimized spole design reduces humming noise by 40% compared to previous generation. Requires 5μm filtration (40μm for emergency use).
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with rapid cycle demands
- Bottle filling/palletizing systems (food grade version available)
- Electric vehicle battery cooling circuits
Installation protocol:
Maximum 10 valves stackable per manifold. Apply Loctite 542 on port threads.
Maintain 20mm clearance below valve for condensate drainage. Lubricate with ISO VG32 oil if air line is un-lubricated.
| Property | Property Value |
|---|---|
| sku | 6HV0510M5C200 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
