Airtac 6HV Manifold Solenoid Valve 6HV0510M5F200
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0510M5F200 Manifold-Mounted Solenoid Valve Specifications
- Model: 6HV0510M5F200
- Type: 5/2-way monostable (spring return)
- Port configuration: M5 manifold mounting
- Port size: Input/Output: M5, Exhaust: φ2.5mm
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 400 NL/min (ANR, at 0.5 MPa)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 60℃ (with no freezing)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection rating: IP67 (dust-tight and protected against immersion)
- Weight: 280g ±5% (excluding manifold)
- Dimensions: 55mm(L) × 24mm(W) × 72mm(H) (single valve body)
- Manifold compatibility: 6HV series modular base with 10mm pitch
- Pilot operation: Internal pilot with built-in silencer
High-density manifold valve designed for multi-valve configurations in automated systems. Features unified air passages for reduced pressure drop and optimized flow path design. The double-seal structure prevents cross-port leakage, with electromagnetic shielding for stable operation in EMC environments. Requires ISO 8573-1 class 3 compressed air (≤5μm particles, ≤0.1mg/m³ oil content).
- Multi-axis pneumatic actuator control in assembly robots
- High-cycle packaging machinery sequencing systems
- Plastic injection molding machine clamp controls
- Automated test equipment with multi-channel switching
- Beverage filling line valve clusters
Installation note:
Maximum 16 valves can be manifold-mounted in series. Apply Loctite 243
(medium strength) on manifold screws. Maintain ambient humidity below 85% RH
with condensation prevention. Lubrication: ISO VG32 turbine oil mist,
1 drop per valve/week.
| Property | Property Value |
|---|---|
| sku | 6HV0510M5F200 |
| Port Size | M5 |
| Standard Voltage | AC12V |
