Airtac 6HV Manifold Solenoid Valve 6HV0520M5A200
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV Series Manifold-Mounted Solenoid Valve 6HV0520M5A200
- Model: 6HV0520M5A200
- Type: 5/2-way double solenoid (monostable return)
- Port size: G1/4 (ISO228/1 standard)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC24V ±10% (standard), AC110V/220V optional
- Max flow rate: 900 NL/min (ANR, at 0.5 MPa)
- Weight: 0.82 kg (1.81 lbs) with manifold base
- Dimensions: 58mm(H) × 40mm(W) × 140mm(L)
- Seal material: Heat-resistant NBR (Nitrile) - optional FKM available
- Temperature range: -5℃ to 80℃ (extended to 120℃ with FKM seals)
- Power consumption: 2.2W (DC24V), 4.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Response time: ≤30ms (energize), ≤20ms (de-energize)
- Manual override: Built-in push-button operator
- Port thread depth: 12mm (minimum engagement)
High-density manifold-mount valve designed for multi-station pneumatic systems requiring sequential control. Features shock-resistant epoxy-coated coil, LED status indicator, and anti-vibration spool design. The modular construction allows up to 20 valves per manifold block. Requires ISO 8573-1:2010 Class 3 compressed air (max 5μm particle size).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Textile machinery tension control
- Semiconductor wafer handling robots
- Beverage filling station diverters
Installation protocol:
Mount on ISO standard manifold base using M5×16mm hex screws (35N·m torque limit).
Maintain ambient temperature below valve rating with ≥50mm clearance above for heat dissipation.
Perform monthly lubrication of air pilot ports using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 6HV0520M5A200 |
| Port Size | M5 |
| Standard Voltage | AC220V |
