Airtac 6HV Manifold Solenoid Valve 6HV0520M5C050
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0520M5C050 Manifold-Mounted Solenoid Valve Specifications
- Model: 6HV0520M5C050
- Type: 5/2-way monostable (single solenoid) with manual override
- Port size: PT1/4 (G1/4 optional)
- Thread type: M5 subminiature connection for pilot line
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Max flow rate: 850 l/min (ANR)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 1.25 kg (including manifold base)
- Dimensions: 72mm(L) × 54mm(W) × 88mm(H)
- Seal material: FKM (Viton) standard, EPDM/NBR optional
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Protection rating: IP67 (coil), IP40 (valve body)
- Porting pattern: ISO 5599-1 standard (CETOP RP52H)
High-density manifold-mount valve with integrated silencer and surge suppression. Features corrosion-resistant anodized aluminum body and shock-resistant coil design. The 6HV series employs a spool-type mechanism with low-friction seals for ≤0.1 MPa minimum operating pressure. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- Multi-station pneumatic automation systems
- Plastic injection molding machine controls
- Automated assembly line clamping mechanisms
- Textile machinery cylinder sequencing
- Semiconductor handling equipment
Installation guidelines:
Mount on ISO standard manifold using M5x16 mounting screws (3.5N·m torque limit).
Maintain ambient temperature below 60℃ with ≥20mm clearance between valves.
Use shielded cable for coil connections in high EMI environments.
| Property | Property Value |
|---|---|
| sku | 6HV0520M5C050 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
