Airtac 6HV Manifold Solenoid Valve 6HV0530CM5A050
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0530CM5A050 Modular Solenoid Valve Specifications
- Model: 6HV0530CM5A050 (Full code breakdown: 6HV Series / 05 Port Size / 30 Function Code / C Coil Type / M5 Voltage Spec / A Seal Material / 050 Special Option)
- Type: 5/2-way double solenoid operated (ISO 5599-1 compliant)
- Port size: G1/8 (ISO228/1 standard) with NPT1/8 optional
- Operating pressure range: 0.15-1.0 MPa (21.7-145 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±5% (including coil and mounting accessories)
- Dimensions: 98mm(L) × 45mm(W) × 72mm(H) (excludes manifold mounting surface)
- Seal material: Heat-resistant FKM (Viton®) standard (NBR optional)
- Temperature range: -10℃ to 80℃ (with FKM seals, up to 150℃ intermittent)
- Flow capacity: CV 1.8 (Kv 1.56) at 0.5MPa
- Response time: ≤25ms (energize)/≤35ms (de-energize) at 0.5MPa
- Power consumption: 3.5W (DC24V), 5VA (AC models)
- Protection rating: IP67 (coil)/IP40 (valve body)
- Port thread depth: 12mm minimum engagement
High-flow modular valve with dual redundant coils, featuring manual override and position indication. The hardened stainless steel spool and anodized aluminum body ensure 10 million cycle durability. Optimized for multi-valve manifolds with 12mm inter-valve pitch. Requires 5μm filtered, lubricated or non-lubricated air (specify when ordering).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with high cycle rates
- Foundry equipment requiring heat resistance
- Multi-station pneumatic test benches
Installation criticals:
Mount horizontally with coil axis vertical. Use flexible tubing for manifold connections exceeding 3 valves.
Apply 24V DC models for PLC direct control (max 10m cable length). Annual spool lubrication recommended in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | 6HV0530CM5A050 |
| Port Size | M5 |
| Standard Voltage | AC220V |
