Airtac 6HV Manifold Solenoid Valve 6HV0530CM5A200
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0530CM5A200 Manifold Solenoid Valve Specifications
- Model: 6HV0530CM5A200
- Type: 5/3-way closed center (manifold mounted)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Weight: 320g ±5% (including manifold base)
- Dimensions: 56mm(L) × 34mm(W) × 86mm(H) per valve body
- Manifold base size: 180mm(L) × 24mm(W) × 42mm(H) for 10 stations
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (with anti-freeze measures below 0℃)
- Power consumption: 2.2W (DC24V), 3.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5MPa)
- Protection rating: IP67 (dustproof & temporary immersion protected)
- Port thread depth: 12mm (minimum engagement 9mm)
High-density modular valve designed for centralized pneumatic control systems. Features dual-color LED status indicators (red/green) and surge protection circuitry. The aluminum alloy manifold base allows multi-valve stacking with integrated air passages, reducing piping complexity by 60% compared to individual valves. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line multi-station tooling
- Plastic injection molding machine clamp control
- Textile machinery pneumatic sequencing systems
- Semiconductor wafer handling robots
- Automotive brake testing equipment
Installation protocol:
Mount on vibration-damped surfaces (max 4.9m/s² acceleration).
Use torque-controlled wrench at 1.5-2.0N·m for manifold screws.
Perform monthly 0.3MPa purge cycle for dust expulsion.
| Property | Property Value |
|---|---|
| sku | 6HV0530CM5A200 |
| Port Size | M5 |
| Standard Voltage | AC220V |
