Airtac 6HV Manifold Solenoid Valve 6HV0530CM5C050
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0530CM5C050 Manifold Solenoid Valve Specifications
- Model: 6HV0530CM5C050
- Type: 5/3-way closed center (solenoid pilot-operated)
- Port configuration: G1/8 (ISO228/1 standard)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±2% (with manifold base)
- Dimensions: 86mm(L) × 35mm(W) × 98mm(H) (single valve stack height)
- Flow capacity: 750 Nl/min (Cv=1.3 at 0.5MPa)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: 2.2W (DC24V), 3.5VA (AC)
- Response time: ≤15ms (exhaust to full open)
- Protection rating: IP67 (coil), IP40 (valve body)
- Manifold compatibility: Up to 16-station modular assembly
High-density manifold valve with integrated silencer and surge suppression, featuring zero differential pressure start capability. The anodized aluminum manifold base enables multi-valve stacking with single-point mounting. Optimized for high-cycle applications (≥50 million operations) with gold-plated connectors for stable signal transmission. Requires ISO 8573-1:2010 Class 3 compressed air.
- Automated assembly line clamping systems
- Multi-axis CNC machine tool changers
- Plastic injection molding ejectors
- Semiconductor wafer handling robots
- Beverage filling station manifold controls
Installation guidelines:
Maintain ≤0.5mm flatness on manifold mounting surface. Use M5x0.8 mounting screws
with 0.8-1.2Nm torque. For multi-station setups, install end plates with 15N·m tightening
force to prevent air leakage. Lubricate seals with ISO VG32 turbine oil if stored >6 months.
| Property | Property Value |
|---|---|
| sku | 6HV0530CM5C050 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
