Airtac 6TA Pneumatic Control Valve 6TA32010
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Compatible with base-mounted integrated valve manifolds, optimizing spatial efficiency in system layouts.
Classification: Air Control Valve | Brand: Airtac | Series: 6TA
AirTAC 6TA32010 Pneumatic Control Valve Technical Details
- Model: 6TA32010 (Pneumatic Pilot-Operated)
- Valve type: 5/2-way double solenoid
- Port configuration: PT3/8 (G3/8 optional)
- Operating pressure range: 0.2–1.0 MPa
- Max operating frequency: 5 cycles/sec
- Seal material: Heat-resistant NBR (+80℃ grade)
- Ambient temperature: -20℃ to 80℃ (with dry air)
- Voltage options: DC12V/24V, AC110V/220V (±10%)
- Effective flow rate: 850 l/min (ANR)
- Response time: ≤15ms (at 0.5MPa)
- Weight: 520g ±3% (including connectors)
- Dimensions: 62mm(L) × 38mm(W) × 85mm(H)
- Body material: Anodized aluminum alloy
- Protection class: IP67 (dust/water resistant)
High-flow directional control valve with dual electrical/pneumatic actuation, featuring anti-vibration coil design and manual override. Optimized for rapid cycling applications with built-in surge suppression. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers & rotary index tables
- Material handling robotics (EOAT control)
- Pressurized cleaning equipment sequencing
Installation guidelines:
Mount using M4 screws with vibration-proof washers. Maintain minimum
15mm clearance below valve for exhaust flow. Use 90%+ purity nitrogen
in high-condensation environments. Lubricate with ISO VG32 turbine oil
if air line lubrication is absent.
| Property | Property Value |
|---|---|
| sku | 6TA32010 |
| Initial Position | Normally Closed |
| Port Size | PT3/8 |
