Airtac 6TV Solenoid Valve 6TV0500M10F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M10F Solenoid Valve Specifications
- Model: 6TV0500M10F
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/8 optional)
- Thread standard: Metric (M5x0.8) or NPT upon request
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Weight: 220g ±5% (without connector)
- Dimensions: 78mm(L) × 32mm(W) × 62mm(H)
- Seal material: Heat-resistant NBR (Nitrile), optional FKM for high temps
- Temperature range: -5℃ to 80℃ (NBR) / -10℃ to 150℃ (FKM)
- Power consumption: ≤2.2W (DC) / ≤3.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Flow capacity: 750 l/min (ANR) at 0.5 MPa
- Protection rating: IP67 (coil), IP40 (valve body)
- Manual override: Optional push-button type
The 6TV0500M10F features a rugged aluminum alloy body with hard anodized finish, designed for high-cycle industrial applications. Its low-friction spool design achieves over 50 million cycles MTBF. The "M10F" suffix indicates metric port threading with fluorine rubber seals. Compatible with ISO 15407-1 standards, it supports both vacuum and pressure applications.
- Pneumatic cylinder control in assembly lines
- Textile machinery clutch engagement systems
- Semiconductor wafer handling robots
- Plastic injection molding machine ejectors
- Beverage filling station air logic circuits
Installation note:
For horizontal mounting, install exhaust port downward to prevent dust ingress.
Use Loctite 545 on threaded ports for leak-free sealing. Minimum 5mm wrench
clearance required for manifold mounting.
| Property | Property Value |
|---|---|
| sku | 6TV0500M10F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
