Airtac 6TV Solenoid Valve 6TV0500M11F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M11F Solenoid Valve Technical Details
- Model: 6TV0500M11F
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤30ms (at 0.5MPa)
- Flow coefficient (Cv): 2.5
- Weight: 400g ±5% (excluding accessories)
- Dimensions: 100mm(L) × 50mm(W) × 70mm(H)
- Seal material: Heat-resistant NBR (-20℃ to 120℃)
- Ambient temperature range: -5℃ to 60℃ (non-freezing)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Manual override: Built-in push-button type
- Port thread depth: 12mm (full thread engagement recommended)
High-flow directional control valve with reinforced brass body for industrial automation systems. Features dual-color LED status indicator (red/green) and surge protection circuit. Designed for continuous duty cycles with 10 million+ mechanical life expectancy. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Automated assembly line actuators
- Plastic injection molding machines
- Textile machinery cylinder control
- CNC pneumatic tool changers
- Food processing conveyor systems
- Bottle filling/capping equipment
Installation guidelines:
Mount with vibration-damping pads in high-shock environments.
Maintain 15° maximum deviation from vertical orientation.
Use copper-free anti-seize compound on threaded ports.
Critical note:
Do NOT use with oxygen/media containing silicone oil.
Allow 2-minute cool-down period after 4hrs continuous operation.
| Property | Property Value |
|---|---|
| sku | 6TV0500M11F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
