Airtac 6TV Solenoid Valve 6TV0500M13F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M13F Solenoid Valve Specifications
- Model: 6TV0500M13F
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/2 (G1/2 equivalent)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±2% (including coil)
- Dimensions: 112mm(L) × 55mm(W) × 78mm(H)
- Flow coefficient (Cv): 2.2 (at 0.5 MPa)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (no freezing)
- Power consumption: DC: 3.5W / AC: 4.2VA
- Protection rating: IP67 (coil), IP40 (valve body)
- Response time: ≤30ms (energized), ≤50ms (de-energized)
- Port thread depth: 13mm (minimum engagement)
High-flow directional control valve with manual override, featuring aluminum alloy body for lightweight durability. Optimized spool design reduces pressure loss by 18% compared to previous generation. Includes LED status indicator and surge protection circuit. Requires 5μm filtered lubricated air (ISO 8573-1:2010 class 4-4-3).
- Pneumatic cylinder sequencing in assembly lines
- Actuator control for CNC machine tool changers
- Material handling systems (conveyor diverters)
- Plastic injection molding machine air circuits
- Automotive tire mounting equipment
Installation guidelines:
Mount with M5 mounting brackets (max torque 2.5N·m). Maintain ≥20mm clearance
below valve for service access. Use PTFE tape on male threads only. Perform
monthly manual cycling during maintenance.
Avoid rapid switching cycles exceeding
5Hz continuously. For vacuum applications, install downstream filter within 300mm.
| Property | Property Value |
|---|---|
| sku | 6TV0500M13F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
