Airtac 6TV Solenoid Valve 6TV0500M14F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M14F Solenoid Valve Technical Details
- Model: 6TV0500M14F
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.15–1.0 MPa
- Max flow capacity: 1200 L/min (ANR)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dust/water resistant)
- Weight: 320g ±5%
- Dimensions: 72mm(L) × 48mm(W) × 85mm(H)
- Mounting pattern: ISO 5599-1 compliant
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with low power consumption design, featuring brass body construction with anodized aluminum solenoid housing. The optimized spool structure ensures ≤0.1MPa minimum operating pressure difference. Includes manual override button for system debugging and emergency operation. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Pneumatic cylinder sequencing in assembly lines
- Material handling equipment (rotary actuators)
- Textile machinery air circuit control
- Semiconductor manufacturing vacuum breakers
- Automated door control systems
Operational guidance:
Install with 15° maximum deviation from vertical axis. Use copper-free
anti-seize compound on threads. Allow 2-minute stabilization after
initial power-up before full-load operation.
| Property | Property Value |
|---|---|
| sku | 6TV0500M14F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
