Airtac 6TV Solenoid Valve 6TV0500M17F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M17F Solenoid Valve Specifications
- Model: 6TV0500M17F
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5%
- Dimensions: 100mm(L) × 38mm(W) × 45mm(H)
- Seal material: FKM (Fluoroelastomer) for high chemical resistance
- Temperature range: -5℃ to 80℃ (with silicone grease below 0℃)
- Flow coefficient (Cv): 1.6
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Power consumption: 2.8W (DC24V), 3.5VA (AC)
- Protection rating: IP67 (dustproof and waterproof)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with manual override, featuring a brass body with nickel plating for corrosion resistance. Designed for medium-duty pneumatic systems requiring rapid cycling (up to 5Hz). Includes LED status indicator and surge suppression circuitry. Compatible with ISO 15407-1 standards.
- Industrial automation: Actuator control in assembly lines
- Packaging machinery: Direction reversal for cylinder movements
- Semiconductor manufacturing: Cleanroom pneumatic systems
- Test equipment: Air circuit switching for leak detectors
- Food processing: Compatible with food-grade lubricants (NSF H1 optional)
Installation note:
Mount with vibration-damping brackets in high-frequency applications.
Use PTFE tape on ports with ≤20Nm torque. Perform quarterly lubrication
maintenance in high-cycle (＞1 million/year) environments.
Critical notice:
Requires 5μm filtration with automatic drain. Avoid continuous
energization exceeding 60 minutes to prevent coil overheating.
| Property | Property Value |
|---|---|
| sku | 6TV0500M17F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
