Airtac 6TV Solenoid Valve 6TV0500M18F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M18F Solenoid Valve Specifications
- Model: 6TV0500M18F
- Type: 5/2-way double solenoid (pilot-operated)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (coil interchangeability)
- Weight: ~420g ±5g
- Dimensions: 58mm(L) × 42mm(W) × 75mm(H)
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 80℃ (with intermittent 100℃ peak)
- Power consumption: ≤2.8W (at DC24V)
- Flow capacity: 750 L/min (ANR)
- Response time: ≤30ms (with 0.5MPa pressure)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with dual-coil latching capability, featuring anti-vibration structure and manual override. The anodized aluminum body ensures corrosion resistance in humid/oily environments. Designed for ISO 15407-1 compliance with 10 million cycle durability. Requires 5μm filtered air with lubricator (ISO VG32 recommended).
- Industrial automation sequencing systems
- Food processing machinery actuators
- Automotive assembly line clamping devices
- High-speed packaging equipment
- Plastic injection molding machines
- Textile machinery pneumatic circuits
Installation note:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15° maximum deviation from vertical orientation.
Always install upstream pressure regulator with gauge (0.05MPa below valve rating).
| Property | Property Value |
|---|---|
| sku | 6TV0500M18F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
