Airtac 6TV Solenoid Valve 6TV0500M19F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M19F Solenoid Valve Specifications
- Model: 6TV0500M19F
- Type: 5/2-way monostable (pilot-operated)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: ~320g (including connector)
- Dimensions: 72mm(L) × 38mm(W) × 52mm(H)
- Seal material: NBR/Viton (optional)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Flow capacity: 1200 NL/min (at 0.5 MPa)
- Response time: ≤30ms (at rated voltage)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (PT series)
- Manual override: Optional paddle actuator
High-flow directional control valve with aluminum alloy body and hardened stainless steel spool. Features low-hysteresis magnetic circuit design for consistent performance in high-cycle applications (up to 5 million cycles). Includes surge suppression diode protection and LED status indicator. Requires 5μm filtered/dried air with ISO 8573-1:2010 Class 3.2.3 air quality.
- Automated assembly line actuators
- Plastic injection molding machines
- Textile machinery tension control
- Automotive brake testing systems
- Food packaging cylinder control
- Semiconductor wafer handling robots
Installation note:
Mount in vibration-free environment with ±3° maximum tilt angle.
Use M3.5 mounting screws (max torque 0.8N·m). Allow 15mm clearance
below valve for manifold heat dissipation. Lubricate seals with
ISO VG32 turbine oil if stored >12 months.
| Property | Property Value |
|---|---|
| sku | 6TV0500M19F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
