Airtac 6TV Solenoid Valve 6TV0500M1F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M1F Solenoid Valve Technical Specifications
- Model: 6TV0500M1F
- Valve type: 5-port, 3-position (center closed)
- Port configuration: 1/4" BSPP (G1/4)
- Operating principle: Double solenoid pilot-operated
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V/24V, AC110V/220V (±10% tolerance)
- Coil insulation class: Class F (155℃)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5 MPa)
- Response time: ≤30ms (open), ≤20ms (close)
- Seal materials: HNBR/Nitrile compound (standard), optional FKM
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Weight: 280g ±5% (excluding accessories)
- Dimensions: 72mm(L) × 34mm(W) × 54mm(H)
- Port thread depth: 10mm (full engagement required)
- Protection rating: IP67 (coil), IP40 (valve body)
- Service life: ≥10 million cycles (under rated conditions)
High-flow proportional control valve with central exhaust configuration, featuring dual manual override buttons and surge protection circuitry. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality standard.
- Pneumatic cylinder sequencing in assembly lines
- Multi-axis actuator control systems
- Plastic injection molding machine clamping units
- Automated material handling equipment
- Test bench pressure regulation systems
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 15mm clearance from adjacent components for heat dissipation.
Lubricate with ISO VG32 turbine oil if using non-lubricated air systems.
Critical note:
Do not energize coils for >85% duty cycle without forced air cooling.
Always install downstream pressure regulators when exceeding 0.8 MPa.
| Property | Property Value |
|---|---|
| sku | 6TV0500M1F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
