Airtac 6TV Solenoid Valve 6TV0500M20F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M20F Solenoid Valve Specifications
- Model: 6TV0500M20F
- Type: 5/2-way monostable (pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Effective area: 17.5mm² (pilot), 24mm² (main valve)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5% (with coil)
- Dimensions: 68mm(L) × 44mm(W) × 78mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: Heat-resistant NBR (up to 120℃ intermittent)
- Temperature range: -5℃ to 80℃ (continuous operation)
- Power consumption: 2.5W (DC), 3.8VA (AC)
- Response time: ≤30ms (exhaust to actuation)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with optimized pilot structure for reduced air consumption. Features dual-chamber sealing technology and shock-resistant coil design. Requires 5μm filtered lubricated air (ISO 8573-1 class 4.4.3). Compatible with vacuum applications when using V-type seals (optional).
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with rapid cycle times
- Textile machinery pneumatic actuators
- Automotive testing equipment
Installation note:
Mount in vibration-free environment using M4 mounting screws (max torque 1.2N·m).
For horizontal installation, use supplied anti-debris shield. Lubricate monthly with ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | 6TV0500M20F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
