Airtac 6TV Solenoid Valve 6TV0500M5F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M5F Solenoid Valve Specifications
- Model: 6TV0500M5F
- Type: 5/2-way monostable (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (with connector)
- Dimensions: 52mm(L) × 40mm(W) × 76mm(H)
- Seal material: FKM (Viton®) standard (NBR available on request)
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.8W (DC), 3.5VA (AC)
- Flow rate: 750 NL/min (at 0.5 MPa)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Protection rating: IP67 (connector installed)
- Port thread depth: 12mm (minimum engagement)
High-flow 5/2-way valve with manual override, featuring brass body construction with hard anodized aluminum sleeve. Designed for industrial automation requiring bi-directional control, its double-seal structure prevents internal leakage even under pressure fluctuations. Compatible with ISO 15407-1 standards. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Double-acting cylinder control in assembly lines
- Pneumatic clamping systems for CNC machinery
- Material handling equipment actuators
- Automated packaging machine sequencing
- Test bench pressure switching systems
Installation note:
For optimal performance, install with 15° downward tilt to prevent condensate accumulation.
Use anti-vibration mounts in high-cycle applications (>1.5 million operations/month).
Minimum 20mm clearance required above pilot vent ports.
| Property | Property Value |
|---|---|
| sku | 6TV0500M5F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
