Airtac 6TV Solenoid Valve 6TV0500M6F
$13.92
Regular price
$21.42
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6TV0500M6F
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Plug-in electrical connection design allows horizontal and vertical terminal mounting orientations to be freely interchangeable;
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M6F Solenoid Valve Specifications
- Model: 6TV0500M6F
- Type: 5/2-way monostable (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.2
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Weight: 320g ±5% (without connector)
- Dimensions: 75mm(L) × 50mm(W) × 62mm(H)
- Body material: Anodized aluminum alloy
- Seal material: NBR (standard), optional FKM/Viton
- Temperature range: -20℃ to 80℃ (NBR seals)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Protection rating: IP67 (dust tight & temporary immersion)
- Port thread depth: 10mm (minimum engagement)
High-flow 5-port directional valve with manual override, designed for precise bidirectional cylinder control. Features low-hysteresis spring return mechanism and impact-resistant coil housing. Requires 50μm filtered dry air with ISO 8573-1:2010 Class 3.4.3 purity standards.
Typical Applications:
- Automated assembly line cylinder reversing
- Textile machinery tension control systems
- Plastic injection molding ejectors
- Automotive tire assembly fixtures
- Food processing pneumatic actuators
Installation note:
Mount with 15mm clearance above coil for heat dissipation.
Use anti-vibration washers when installed on machinery with >5G acceleration.
Lubricate seals with ISO VG32 pneumatic oil if used in dry environments.
| Property | Property Value |
|---|---|
| sku | 6TV0500M6F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
