Airtac 6TV Solenoid Valve 6TV0500M7F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M7F 5/2-Way Solenoid Valve Specifications
- Model: 6TV0500M7F
- Type: 5/2-way monostable (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 280g ±5%
- Dimensions: 55mm(L) × 30mm(W) × 60mm(H)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -20℃ to 80℃ (with 1hr max. at 100℃)
- Power consumption: 2.2W (AC), 1.8W (DC)
- Response time: ≤20ms (exhaust to full actuation)
- Flow coefficient (Cv): 1.2
- Protection rating: IP67 (dust/water resistant)
High-flow directional control valve with integrated silencer and manual override. Features brass body with hard anodized aluminum core for corrosion resistance in humid environments. Designed for 1 million+ cycle durability with ≤0.5L/min leakage rate. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 quality.
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery clamp control systems
- Food processing vacuum/pressure switching
- Semiconductor wafer handling equipment
- Hydraulic system pilot control circuits
Installation guidelines:
Mount with M4 screws (max torque 1.2N·m). Lubricate with ISO VG32 turbine oil
if used below -10℃. Maintain 20mm clearance from heat sources.
Use shielded cables for EMI-sensitive environments.
| Property | Property Value |
|---|---|
| sku | 6TV0500M7F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
