Airtac 6TV Solenoid Valve 6TV0500M8F
$16.71
Regular price
$24.21
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6TV0500M8F
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Plug-in electrical connection design allows horizontal and vertical terminal mounting orientations to be freely interchangeable;
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M8F Solenoid Valve Specifications
- Model: 6TV0500M8F
- Type: 5/2-way monostable (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Max flow rate: 1200 NL/min
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10%)
- Weight: 450g ±5%
- Dimensions: 112mm(L) × 42mm(W) × 60mm(H)
- Body material: Aluminum alloy (anodized)
- Seal material: FKM fluorocarbon (standard) / NBR optional
- Temperature range: -5℃ to 80℃ (with FKM seals)
- Response time: ≤15ms (at 0.5MPa)
- Power consumption: 2.2W (DC) / 3.5VA (AC)
- Protection rating: IP67 (dustproof & waterproof)
- Port thread depth: 12mm (minimum engagement)
High-flow 5/2-way valve with metal piston structure, optimized for rapid cycling applications. Features double-layer coil winding for enhanced heat dissipation and manual override capability. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
Typical Applications:
- Industrial automation: Cylinder control in assembly lines
- Textile machinery: Pneumatic actuator sequencing
- Food processing: Air knife control systems
- Semiconductor manufacturing: Vacuum/pressure switching
- Automotive testing: Brake simulation systems
Installation note:
For optimal performance, install with 15° downward tilt to prevent condensate accumulation.
Use flexible tubing for the first 200mm of connections to reduce vibration transmission.
| Property | Property Value |
|---|---|
| sku | 6TV0500M8F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
